K Swap K Series K20 K24 Turbo Sidewinder Manifold Intercooler GT35 T3 T4 .63 .82 60mm

Details

K Swap K Series K20 K24 Turbo Kit Sidewinder Manifold Intercooler GT35 EG
EK T4

Intercooler Info: Key Features:

Core Size: 24″ x 7″ x 3.5″
Overall Size: 27″ x 12.5″ x 3.5″
Air to air intercooler core

High density, high quality core
Bar and plate construction
3″ inlet 3″ outlets
Rated for 600HP

Manifold Info: This manifold design fits every Honda K-Series chassis
from K-Swap’s, CRX, Civic, Integra, EP3 Civics and RSX.

Key Features:Brand New In BoxFor K-Series K20 K24 MotorMade of 304 grade
stainless steelOne year limited warrantyCNC machined manifold flangeFlange is
1/2 inch thickThick 8 gauge / Schedule 40 pipeOne piece design 60mm wastegate
flangeFlanges surfaced for perfect sealFully portedLow angle merge
collectorProfessionally TIG welded and assembledCoolant lines may need to be
modified or reroutedComes Exactly As Pictured

Turbo Info: Compressor wheel: 65.7/82.6/85.3mmCompressor Housing: 0.72
A/R Anti-Surge, 4″ Inlet, 2.5″ OutletTurbine wheel: 68mm/62.3mmTurbine
housing: T4 Inlet, V-Band 3″ Outlet, A/R 0.82Oil inlet:7/16-24UNF
