A/R 63 STAGE III T04E T3 T4 73 TURBINE Turbo W/Intercooler +Piping Pipe Kits

Details

Application

This item fits: Universal Application.
Compatible for 1.5L to 2.5L any 4/6 cylinder engine up to 400+ HP
Maximum 18PSI

Note:Please confirm that your car’s displacement is between 1.5-2.5L .

Please check the size before purchasing and make sure that your car has enough
space to install this turbo.

Specification

Exhaust (Turbo Manifold) Flange: T3 T4 4 bolt Flange Patterns

Exhaust (Downpipe) Flange: Standard T3 5 bolt downpipe flange pattern

Cooling Type: Oil Cooled

Wastegate: External Wastegate

Compressor

Trim: 48.1

A/R: 0.5

Inducer: 52.7

Exducer: 76

Turbine:

Trim: 74.2

A/R: 0.63

Inducer: 64.8

Exducer: 55.8

Turbine exhaust outlet :

Turbine exhaust inlet44.5mm/81mm

Compressor outlet45mm(inside diameter)53mm(Outer diameter)

Compressor inlet68 mm(inside diameter)72mm(Outer diameter)

Oil Inlet: M121.25

Oil Outlet:2M81.25

Intercooler Information

Inlet / outlet size : 2.5″

Core size : 21”x 7”x 2.25”/550x175x64mm

Full size: 27.00″ (L) X 7.00″ (H) X 2.50″(W)

Compress Air Flow Rate350Cubic Feet/Min, Rated up to500 Max HP

Pressure drop: 2~5psiat35psi, 0.2~0.5psiat15psi

Material: Aluminum alloy

Core design: Tube Fin

Applaction: Universal

Intercooler Piping Pipe Kit Information

ApplicationUniversal fits all Turbo Projects

Description

Pipe Thickness: 1.8mm

Pipe length: 18”

Package Included:You will get exactly as shown in the picture above

Condition: New

Notice

Professional installation is highly recommended (No Instruction)

For any needs please contact us

Replace, repair or reconnect air cleaner element per manufacturer’s manual to avoid compressor wheel damage.

Make sure the oil drain line is lower than the turbo itself.

Gasoline car must install a water cooling device to avoid overheating.

Ensure exhaust outlet are well sealed by welding.
